No.	Project	Parameter
1	Batteries materials：	Lithium iron phosphate
2	Series parallel mode (S series, P parallel)：	4S1P
3	Nominal voltage：	12.8V
4	Nominal capacity:	100Ah
5	Size（mm）：	300*170*180
6	Weight：	11.5kg
7	Output port mode：	terminal
8	Charging way：	CC/CV
9	Charging current：	0.2C（standard）
10	Maximum charging current：	Max1C @25°
11	Charge cut-off voltage：	14.6V
12	Discharge way：	CC
13	Discharge current：	0.5C
14	Maximum discharge current：	Max1C @25°
15	Discharge cut-off voltage：	11.2V
16	According to：	LCD
17	Communication interface:	Bluetooth
18	Charging operating temperature：	charging0~+50℃
19	Discharge operating temperature：	discharge-20~+55℃
20	The quality assurance period：	24 months

      　　BENEFITS 　　ENHANCED RUNTIME

• 　　Double the high-current runtime of lead-acid battery
• 　　Up to 100% usable capacity
• 　　Up to 100% depth of discharge

　　EXTENDED SERVICE LIFE

• 　　10x the life of lead-acid battery (BCI-06)
• 　　Unlimited Partial State of Charge cycles
• 　　10-year energy throughput warranty

　　FAST CHARGING

• 　　Up to 5x faster than new lead-acid batteries
• 　　Up to 10x faster than aged lead-acid batteries
• 　　2X faster charging than C/2 Rated lithium batteries
• 　　1C continuous charge rate, regardless of SoC

　　SURGE POWER

• 　　Power for off-grid inverter surge demands
• 　　Up to 3C peak power discharge rate
• 　　1C continuous discharge rate

　　HIGH-EFFICIENCY

• 　　Up to 50% more energy efficient than a lead-acid battery
• 　　Up to 98% round-trip efficiency

　　DYNAMIC PERFORMANCE

• 　　Real-time optimization of the charge rate
• 　　Faster recharge from 0% to 100% SoC than lead-acid battery

　　PARALLEL POWER

• 　　Easy to parallel more capacity
• 　　Linear scaling of charge, discharge and peak capacity
• 　　Parallel up to 20 batteries or 160 kWh per LYNK device

　　QUICK INSTALL

• 　　Fast installation. No special tools
• 　　Drop-in lead-acid replacement

　　RELIABLE AND SAFE

• 　　LiFePO4 is thermally safe
• 　　Maintenance-free
• 　　Steel case and cover
• 　　IP 55 rated

　　CERTIFIED QUALITY Discover® manufacturing facilities are fully certified to ISO 9001/14001 and OSHA 18001 standards. 　　CERTIFICATION STANDARDS

• 　　IEC 62619
• 　　UL 1973
• 　　UL 9540
• 　　CE
• 　　UN 38.3

Company Profile：

Guangzhou Geerady Solar Technology Co.,Ltd is located in Shenzhen, China. Geerady solar is a high-tech new energy enterprise with research and development, production, project design and installation guidance and after-sale service.

Geerady solar was found in 2020 possessed deep pockets and the professional ability of technology and had formed many modern solar panel production lines,LED street light production lines and the testing systems for solar power and lighting. We had plenty of practiced employees and introduced advanced production equipment and manufacturing technique from oversea and motherland.

Through dedicated researches and continuous innovation, we possess unique technology superiority and product superiority. We always concentrated on analyzing customer's market and the application environment of products and provided the high quality solar panel,LED products,solar power and lighting system and so on,all were based on customers'needs.

We had a lot of experience for solar projects which met customers'requirement to provide technical installation guidance on the scene. We had many agencies who in Africa,Eastern Europe,Southeast Asia and so on can provide the satisfying after-sale service to customers.

We execute ISO9001 strictly and produce the solar products under the strict management. Many of our products have been proved by CE,ROHS,SONCAP, etc. We cooperate with the partners from Australia,Turkey,UAE,Singapore,Serbia,Nigeria, etc. And our products have covered more than 50 countries and regional markets. Looking into the future, we are still devoted to a low-carbon,energy saving,environment-friendly life with high-end PV technology and supply the best solar products for thousands of households.

FAQ：

Q: Are you trading company or manufacturer?

A: We are DELONG original factory from shenzhen , China.

Q. Can I print my LOGO on it?

A: YES, LOGO/sticker/OEM/ODM welcomed

Q. Can your battery be wired in series or parallel?

A: YES，YOU can connect up to ANY of these batteries in parallel. For series, suggest within 3 units.

Q. Can the bms be removed and replaced if it breaks? Can the case be opened to replace a bad cell?

A: YES, the case can be opened to replace the BMS & cells on the guidance of engineer.

Q. What warranty do I have?

A: Warranty: 3 years, we would provide repair or replacement with the warranty period.if any quality problems on our side in this period, Please show us video or photos for confirm before we sent solution.

Q: Do you accept OEM/ODM?

A: Yes,it is available.We have OEM group to design battery case.

Q. Do you have Blue-tooth communication with your batteries?

A: Yes, please let us know if you NEED to add Blue-tooth communication with the batteries. and YOU can rename your battery in the App.

Q. Does the app allow to check the voltage of each cell?

A: YES, the App allows you to read the voltage of each at any time.

Q:Are you battery real capacity?

A: All of our battery cells with Grade A,100% new and real capacity. We promise 100% Top grade A. If you found it is not A battery cell, you can contact us for refund.

Q: What kind of certificates do you have?

A: We can provide CE,ROHS,FCC,IEC62133,MSDS,UN38.3 etc.

Q:Do you have MOQ ?

A:No limited. Small order also welcome.More quantity has better price, we will check the best price for you.

Q: What is your term of payment?

A: We adopt T/T,Paypal,Alibaba payment way and so on. If order amount>10K usd, The payment term will be 30%T/T for deposit and the balance before shipment

Q. If your lithium battery goes into protection mode, how do you wake it up?

A: Using lithium chargers to wake up the battery. The lithium charger wakes up the batteries automatically.
